Wall-mounted water purifier Mold

As the professional manufacture, we would like to provide you high quality Wall-mounted water purifier Mold. And we will offer you the best after-sale service and timely delivery.We are a professional China Wall-mounted water purifier Mold manufacturer, if you want to know more, you can contact us.
Recently, we have created a new mold for our customers, a new water purifier manufacturing mold, and the new mold has been assembled.

Send Inquiry

Product Description

As the professional manufacture, we would like to provide you high quality Wall-mounted water purifier Mold. And we will offer you the best after-sale service and timely delivery.

Mould Name: Wall-mounted water purifier Mold




Part size: 600X400X80



Mould cavity No.: 1 cavity



Mould size: 900X650X500



Suitable Injection machine: 530 Ton



Mould Material: NAK80 for core and H13 cavity,slider. S50C for mold base



Mould feeding gate system: Hot runner



Mould Ejection system: Lefter and ejector



Mould cycle time: 40 Seconds



Mould life time: 600k Shots



Mould guarantee: Five year warranty and maintance service supports



Mould Package: Painted with anticorrosive paint and wrapped with plastic film by export standard wooden case.



Mould lead time: 45 days for T1 after deposit



Mould payment: 30% deposit,70% before shipment


How to place an order?


Our company not only sells Portable Air Cooler Mold, Mini Juice Blender Mold, Bulkhead Lamp Plastic Mold from production to customers, but also pays more attention to matching them with the most suitable users. So far our products have been exported to all over the world We always follow the management principles of science first, quality first, and customer first, with the goal of promoting product structure optimization and production standardization. We will sincerely cooperate with friends from all walks of life with our excellent products and perfect service, and welcome new and old customers to visit our company, discuss cooperation and work together for common benefit.

Only need you sent us your 3D or CAD part file, we give you price with 20% discount than other supplier.




Before design the water purifier molds, there are a lot of issue should be take into consideration, such as the demoulding angle,ejector,feeding gate system, cooling water system and how to make the parting line. We have completely solution and experience for making perfect water purifier molds with high quality.

Based on our many years of experience, not only learning the advanced level of the industry, but also through our own repeated experiments to compare and improve, we promise that our Injection Plastic Wall Mounted Water Purifier Cabinet Mould has the most reliable and stable performance. We consistently regard quality and service as the company's goal. With a rigorous work style, we will achieve high-quality quality and perfect service without compromise, so that customers feel that choosing us is to choose peace of mind. Our business puts emphasis on the administration, the introduction of talented personnel, as well as the construction of team building, trying hard to further improve the standard and liability consciousness of staff members customers.



Processing information

The listed values are recommendations. Higher values should be used for higher glass loadings. We recommend only de-humidifying or vacuum dryers. Extensive drying can cause filling problem and surface defects.



1 Feed section                                                 60-80



2 Temperature zone 1 - zone 4                     260-300



3 Nozzle temperature                                    270-310



4 Melt temperature                                        280-300



5 Mold temperature                                       80-100



Holding pressure, spec.                                     300-800 bar



Back pressure, spec.                                           50-150 bar



Injected speed                                                     medium to high



Screw speed                                                         8-15m/min



6Drying time                                                    0-4H



       Drying temperature(τ ≤ -30°C)                   80



       Processing moisture                                     0.02-0.1%



*Physical properties                                                                     Value                         Unit                        Test Standard



      density                                                                                       1360                         kg/m³                         ISO 1183



*Mechanical properties                                                               Value                         Unit                        Test Standard



      tensile modulus(1mm/min)                                                   9700                         Mpa                          ISO 527 2/1A



      tensile stress at break(5mm/min)                                         170                           Mpa                          ISO 527 2/1A



      tensile strain at break(5mm/min)                                         2.1                            %                                ISO 527 2/1A



      flexural modulus(23)                                                          9000                         Mpa                           ISO 178



      flexural strength(23)                                                           280                           Mpa                           ISO 178



      charpy notched impact strength @ 23℃        23                             KJ/m³        ISO179/1eA



*Thermal properties                                                                    Value                         Unit                         Test Standard



      DTUL @ 1.8 Mpa                                                                      252                            ℃       ISO 75-1/-2
