Plastic Drum Roller Washing Machine Mould

Plastic Drum Roller Washing Machine Mould

Mold Specifications

Mold Name:Plastic Drum Roller Washing Machine Mould

Product Description:Roller washing machine drum

Mold Cavity:1 cavity

Mold Size: 1150X850X680mm

Suitable Machine: 850Ton

Mold Main Material: 718H

Mold Injection System: Anole hot runner 4 tips

Mold Ejection System: ejector pin

Mold Cycle Time:72 Seconds

Mold Running: 500K

Delivery Time: 75 working days

Mold Features:high tooling precision

The main advantage of Aoxu Mould in home appliance mould such as washing machine mould, is the surface finish and the plastic assembling effect of the washing machines. As you know all the plastic home appliance parts, specially the famous brand such as LG, SEMENS and so on, the assembling effect is extremely important for the brand. Therefore, high tooling precision is a must. To choose the most shining steel like NAK80 steel, is helping a lot in the finish the polish. And due to the material character, on high HRC, the mould still remain very high tooling capacity. Therefore, after long term running, the plastic mould is running still perfect in parting line and last shining.

Mould Design

1) Mold structure design

Professional designers provide you with reasonably designed mold to shorten cycle hours.

Reducing unnecessary procedure improves efficiency.

2) Mold cooling system

According to the structural characteristics of the product and the appearance of the product , We design a reasonable form of gate for mold, such as a large gate, hidden gate, fan gate, needle gate, pin point gate etc., a reasonable channel of runner design make mold temperature balance in the shortest time to improve mold precision and productivity.

3) Accessory for mold

Slide, guide pin, guide sleeve, lifter blocks and so on are taken by wear-resistant standard parts, to ensure the mold life.

4) Deal with mold

Quenching the mold, heat treatment to improve the hardness, then Nitriding temperature is lower , the mold will no longer need to quench mold with high surface hardening.

Plastic Drum Roller Washing Machine Mould Try-out

To a certain extent, we test the mold only to find out the problems existing in the mold, not to solve them. Therefore, the mold test is divided into several steps, including empty running, high pressure holding, high-speed injection and related long-time mold running detection.

We'll test the mould again after polishing,then send customer the final sample and video of mold test to confirm.

Through the accurate analysis of mold design, processing steps and plastic mold structure, we provide a perfect solution for customers.Mold inspection involves many aspects, such as: mold strength, mold flow analysis, mold injection, cooling system, guide system, specifications of various parts, customer machine selection and customer special mold requirements, etc., all of which should be tested according to the mold design standard.

Mould Manufacturing Culture and service

HongMei mould manufacturing culture is particular. We believes that if we do everything based on RESPONSIBILITY, all thing are well done. Thus, our Mold Manufacturing core culture is responsibility.

HongMei Mould has so many important points and all of them must be well done during the mold manufacturing. The action included:

-Inquiry from customer before mold manufacturing.

During this processing, the communicators of both sides should offer the correct information or specification to be sure that the pricing and technical points are meeting buyer's requirements.

-During the Manufacturing, the designer needs to be responsible to make the mold design. This responsibility is to customer and to company too, he has to consider how the customer use this mold, how to design the mold into long life tool, how to design the related components to make it easier tooling during the Mold Manufacturing and higher precision.

-Mold components machining during the Mold Manufacturing.

The machine operators with strong responsibilities, then the mold components can be precise enough to meet the drawings tolerance requirements. Here the responsibilities are indicated by careful steel installation, rigorous machining process following and rigorous dimension controlling during and after the machining. Otherwise, the errors will extend to the next processing. This will cause the terrible delaying on the mold shipment.

-Mold components dimension controlling after the machining. During the Manufacturing, the cavities, cores and other mold components, after the machining, they need serious dimension controlling. CAM team is responsible to be sure that all the dimensions are according with the drawings.

And Mold assembling workshop, mold mass production simulation workshop, all of them they need to be responsible to be sure that the Mold Manufacturing is successful and the delivered mold is top quality according with HongMei Mould standard.
